Safety Tilt Crucible Furnace - CM450
This easy to use furnace is ideal for fast melts of aluminium. The unit incorporates the Flamefast tilt and pour principle, which ensures safer metal pouring and extended crucible life.
Top Key Features
- Piezo ignition and flame failure device
- Super efficient insulation
- ATP10 capacity crucible pot
- Crucible lid
- Tilt handle
- Pouring gauge
Overview
This easy to use furnace is ideal for fast melts of aluminium. The unit incorporates the Flamefast tilt and pour principle, which ensures safer metal pouring and extended crucible life.
If required, the drum assembly can be detached and carried to the mould using the Combined Lifting and Pouring Tools which are supplied as optional extras.
Key Features
- Piezo ignition and flame failure device
- Super efficient insulation
- ATP10 capacity crucible pot
- Crucible lid
- Tilt handle
- Pouring gauge
- Degassing plunger
- Skimming ladle/dross lifter
- Safety burner
- Cut-out prevents burner from operating when the drum is tilted
- Operation/Instruction manual
Dimensions
| Width: | 450 mm |
|---|---|
| Height: | 330 mm |
| Depth: | 330 mm |
| Weight (Net): | 20 kg |
| Weight (Gross): | 20 kg |
Technical Specifications
| Electrical: | 3A fused spur required for interlock solenoid only |
|---|---|
| Frame Material: | 50 mm Solid beech timber |
| Extraction System: | Integral HEPA extraction system |
| Safety: | IMPORTANT: Fume Extraction is mandatory as per HSG258 / COSHH regulation. Please contact us for advice and cost. |
| Warranty: | 2 Years |
PLEASE STATE GAS TYPE WHEN ORDERING
IMPORTANT NOTICE: ACCORDING TO THE HEALTH & SAFETY AT WORK ACT 1974, BS 4163 AND COSHH REGULATIONS IT IS MANDATORY THAT ALL FUMES MUST BE REMOVED AT SOURCE.
Performance
Forging Performance
| Gas Type | Rate | BTU / HRS | kW | Pressure |
| Natural gas | 0.94 m3/h | 34,500 | 10.1 | 20 mbar |
| Propane | 0.7 kg/h | 34,500 | 10.1 | 35 mbar |
| Butane | 0.68 kg/h | 34,500 | 10.01 | 28 mbar |
Â
MELTING TIMES
| Typical Melting Times from Cold | |
| Aluminium: | 2.9 kg in 25 minutes |
|---|---|
Optional Extras
- Replacement ATP10 crucible pot and lid
- Raised sand tray, 1200 x 800 x 300 mm (no need for a casting pit)
- Face shield
- Heat resistant gloves
- Chrome leather leggings
- Chrome leather apron
- Combined lifting and pouring handles for multiple pours
- Hardware support casting kit
- Moulding Bench
- *Fume extraction to meet the requirements of COSHH Regulations
Â
*Fume extraction is mandatory as per HSG258/ COSHH regulations. Please contact us for advice and cost
-
